DescriptionThe IOGEAR USB to 2-port Serial RS-232 Converter provides two RS-232 serial connectors via one single USB port. You can instantly enjoy connectivity with modem, PDA, POS, and other serial devices on your PC or Mac without the hassle of opening your computer case. It provides a quick, simple, and cost-effective solution and is ideal for various communication and automation applications. The sturdy aluminum case with detachable USB cable design fits your commercial use or everyday connectivity needs. Features
- Two High-Speed RS-232 DB-9 male connectors support data rates up to 230 kbps, twice the speed of a standard PC serial port
- Dual data buffers for each upstream and downstream data transfer to ensure performance
- Slim aluminum design for durability & portability
- Detachable USB cable to fit any specific applications
- No external power adapter required
- LED indicators for adapter status and data activity
- Automatic IRQ and I/O Address Selection
- Two 16C450/16C550 Compatible UARTs
- Supports Transmit-Receive FIFO at 512 bytes per port
- Fully compliant with USB 2.0 & USB 1.1
- Supports power management and automatic handshake mode
- Supports hot-swapping and plug-and-play
Warranty: 3-YEARFunction Diagram RequirementsFor PC Users
- Windows® 2000, Server 2003, XP*, Vista (32-bit/64-bit)
- Available USB port
*Vista driver supports both XP & Vista
For MAC Users
- Mac OS 10.3.9 and up
- Available USB port
Package Content
- 1 x USB to Serial adapter
- 1 x USB Cable
- 1 x Quick Start Guide
- 1 x Installation CD
Specifications UPC: 881317010964 | Function | GUC2322 |
|---|
| Housing | | Case | Aluminum | | LEDs | | Power On | 1 (Orange) | | Port Status | 2 (Green) | | Power Consumption | 0.5 W | | USB Specification | USB 1.1 compliant; USB 2.0 compatible | | Data Rate | 115.2 Kbps | | Connectors | | USB | 1 x USB Type B Female | | Serial | 2 x DB-9 male | | Environment | | Operation Temperature | 0 to 55 degree C ; 32 to 130 degree F | | Storage Temperature | 0 to 70 degree C ; 32 to 155 degree F | | Humidity | 20% - 80% RH, Non-condensing | | Device Connection | 2 | | RS-232 Signal | TXD, RXD, RTS, CTS, DTR, DSR, DCD, RI, GND | | Data Bit | 5, 6, 7, 8 | | Stop Bit | 1, 1.5, 2 | | Power Mode | Bus Powered | | Transmit - Receive FIFO | 512 Bytes per port | | Power Management | Yes |
| Dimensions | GUC2322 |
|---|
| POP Information | | 10'' Peg Hook | 6 | | 6'' Peg Hook | 4 | | Unit Dimensions | | Width | 4.51 inch | | Height | 1 inch | | Depth | 2.24 inch | | Inner Pack | | Width | 13.25 inch | | Height | 7.25 inch | | Depth | 5.5 inch | | Inner Pack Qty. | 6 | | Unit Package Dimensions | | Width | 6.125 inch | | Height | 8.25 inch | | Depth | 1.5 inch | | Master Carton | | Width | 16 inch | | Height | 11.5 inch | | Depth | 7.75 inch | | Master Carton Qty. | 12 | | Weight | | Master Carton Wt. | 10 lb | | Inner Pack Wt. | 4.4 lb | | Unit Pack Wt. | 0.75 lb | | Unit Wt. w/accessories | 0.6 lb | | Unit Wt. | 0.5 lb |
The IOGEAR USB to 2-port Serial RS-232 Converter provides two RS-232 serial connectors via one single USB port. You can instantly enjoy connectivity with modem, PDA, POS, and other serial devices on your PC or Mac without the hassle of opening your computer case. It provides a quick, simple, and cost-effective solution and is ideal for various communication and automation applications. The sturdy aluminum case with detachable USB cable design fits your commercial use or everyday connectivity needs.
- Two High-Speed RS-232 DB-9 male connectors support data rates up to 230 kbps, twice the speed of a standard PC serial port
- Dual data buffers for each upstream and downstream data transfer to ensure performance
- Slim aluminum design for durability & portability
- Detachable USB cable to fit any specific applications
- No external power adapter required
- LED indicators for adapter status and data activity
- Automatic IRQ and I/O Address Selection
- Two 16C450/16C550 Compatible UARTs
- Supports Transmit-Receive FIFO at 512 bytes per port
- Fully compliant with USB 2.0 & USB 1.1
- Supports power management and automatic handshake mode
- Supports hot-swapping and plug-and-play
Warranty: 3-YEAR
For PC Users
- Windows® 2000, Server 2003, XP*, Vista (32-bit/64-bit)
- Available USB port
*Vista driver supports both XP & Vista
For MAC Users
- Mac OS 10.3.9 and up
- Available USB port
- 1 x USB to Serial adapter
- 1 x USB Cable
- 1 x Quick Start Guide
- 1 x Installation CD
UPC: 881317010964 | Function | GUC2322 |
|---|
| Housing | | Case | Aluminum | | LEDs | | Power On | 1 (Orange) | | Port Status | 2 (Green) | | Power Consumption | 0.5 W | | USB Specification | USB 1.1 compliant; USB 2.0 compatible | | Data Rate | 115.2 Kbps | | Connectors | | USB | 1 x USB Type B Female | | Serial | 2 x DB-9 male | | Environment | | Operation Temperature | 0 to 55 degree C ; 32 to 130 degree F | | Storage Temperature | 0 to 70 degree C ; 32 to 155 degree F | | Humidity | 20% - 80% RH, Non-condensing | | Device Connection | 2 | | RS-232 Signal | TXD, RXD, RTS, CTS, DTR, DSR, DCD, RI, GND | | Data Bit | 5, 6, 7, 8 | | Stop Bit | 1, 1.5, 2 | | Power Mode | Bus Powered | | Transmit - Receive FIFO | 512 Bytes per port | | Power Management | Yes |
| Dimensions | GUC2322 |
|---|
| POP Information | | 10'' Peg Hook | 6 | | 6'' Peg Hook | 4 | | Unit Dimensions | | Width | 4.51 inch | | Height | 1 inch | | Depth | 2.24 inch | | Inner Pack | | Width | 13.25 inch | | Height | 7.25 inch | | Depth | 5.5 inch | | Inner Pack Qty. | 6 | | Unit Package Dimensions | | Width | 6.125 inch | | Height | 8.25 inch | | Depth | 1.5 inch | | Master Carton | | Width | 16 inch | | Height | 11.5 inch | | Depth | 7.75 inch | | Master Carton Qty. | 12 | | Weight | | Master Carton Wt. | 10 lb | | Inner Pack Wt. | 4.4 lb | | Unit Pack Wt. | 0.75 lb | | Unit Wt. w/accessories | 0.6 lb | | Unit Wt. | 0.5 lb |
|
