2 Port VGA KVM Switch, PS2 and USB

More Views

2 Port VGA KVM Switch, PS2 and USB



UPC: 881317511683 Availability: EOL
Plug-N-Play - Share two computers using a keyboard, mouse and VGA monitor (2048x1536). Cables included.
This product is EOL and is no longer being sold.

MSRP: $59.95

  • Control and switch between two computers
  • USB or PS/2 computers from one set of keyboard, mouse, and monitor
  • Plug-N-Play - No software needed
  • Built-in USB 2.0 hub
  • Multiple switching method: push buttons, hotkeys, or mouse

2-Port VGA KVMP Switch with USB & PS/2 Interface

IOGEAR's 2-Port VGA KVMP Switch allows full control and switching between your two computers from a USB or PS/2 keyboard, mouse, and VGA monitor. This 2-Port switch supports up to 2048x1536 video resolution, perfect for home or small/medium office environment. With a built-in USB 2.0 hub, EDID support, and complete keyboard and mouse emulation, this VGA KVMP switch easily centralizes your system while expanding your connectivity.

Simple Operation for an Expanded Connectivity

True Plug-N-Play, simply connect the included cables into their appropriate ports without any software to configure or install. Easily switch between your two computers via push button, hotkey combination, or mouse*. Expand your peripherals sharing such as hard drive and printer/scanner from the integrated USB 2.0 ports. Daisy chain a powered USB hub for a more expanded peripheral connectivity workstation. In addition, IOGEAR's DynaSync™** provides EDID support; this feature reads and remembers the monitor's optimal display parameters and refresh rate, eliminating delay when switching between computers.

Secure Switching

This VGA KVM switch also offers a cost effective solution to increase security by allowing users to switch between the Internet connected PC and an Intranet connected PC. With the included cables and adapters, IOGEAR's 2-Port USB VGA KVMP Switch is a true out-of-the-box Plug-N-Play solution to your connectivity needs!

*Only on 3-button wheel mouse with mouse emulation turned on

**IOGEAR's DynaSync provides the EDID support for Windows 7

  • Control 2 computers with one keyboard, mouse and monitor
  • 2-Port VGA KVM
  • Video resolution: 2048x1536; DDC2B
  • Switch between computers via push buttons, hotkeys or mouse
  • USB or PS/2 mouse and keyboard peripherals
  • OS Support: Windows, Linux, Mac and Sun
  • Video DynaSync™ optimizes display resolution and eliminates boot-up display problems
  • Supports widescreen resolutions
  • Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
  • Complete keyboard emulation for error-free booting
  • Mac/Sun keyboard support and emulation
  • Multilingual keyboard mapping – supports English, Japanese, and French keyboards
  • Gaming keyboard support
  • Auto Scan Mode for monitoring all computers
  • Firmware upgradable
  • Power supply not required
  • Console:
    • A VGA compatible monitor capable of the highest possible resolution
    • A standard 2 or 3 button wired USB or PS/2 mouse
    • A standard 104 key wired USB or PS/2 keyboard
  • Computers:
    • The following equipment must be available on each computer:
    • A VGA port
    • Type A USB ports or 6-pin Mini-DIN PS/2 ports
  • Operating Systems:
    • Windows® XP, Windows Vista®, Windows® 7, Windows® 8, Windows® 8.1, Windows® 10
    • Mac OS 9 to 10.x
    • Oracle® Solaris
    • Linux®, Unix and other USB supported systems*

*Additional drivers and support may be needed

  • 1 x GCS1722 2 Port VGA KVM Switch, PS2 and USB
  • 2 x 4ft Custom KVM Cable sets
  • 1 x User Manual
  • 1 x Warranty Card
Distributor Part #
Ingram TQ7610
DH GCS1722
Synnex 5204510
GCS1722 EAR99
Console Connectors
Keyboard & MouseUSB and PS/2
CPU Connectors
Keyboard, Mouse, and MonitorSPHD-18
Cable Length2 x 4ft KVM Cable
Unit Dimensions
Height1.81" (4.60 cm)
Length5.13" (13.03 cm)
Depth2.94" (7.47 cm)
Unit Package Dimensions
Height6.38" (16.21 cm)
Width9.50" (24.13 cm)
Depth2.38" (6.05 cm)
Master Carton
Height7.38" (18.75 cm)
Width15.00" (38.10 cm)
Depth10.25" (26.04 cm)
Master Carton Qty.6
Master Carton Wt.14.88 lb
Unit Pack Wt.2.25 lb
Unit Wt.1.05 lb
